Aluminum Alloy tube & pipe
Classification :
PRODUCT DETAILS
Manufacturing Technique: Hot Rolled, Cold Drawn, Cold Rolled, Forged.
Standard: AISI, ASTM, JIS, GB, DIN, etc. Related Standard: ASTM B210 / B210M, ASTM B241 / B241M, ASTM B221/ B221M, ASTM B 211 ASME SB 211 / ASTM B 619 ASME SB 619.etc
Surface: Mill, polished, bright, hair line, brush
Color:Silver, White,Bronze,Gold,Black,Champagne, Or customized
Film Thickness:Anodized:12-25 μm,Powder coating:40-80 μm
Description:
-
Pipe Type: Aluminum alloy round tube, aluminum alloy square tube, aluminum alloy rectangular tube, aluminum alloy hexagonal tube, high precision ultra-fine ultra-thin aluminum tube
Outside Diameter: 1/2’’mm - 750mm
Thickness: ≥0.3mm
MOQ: 1 Ton
Grade： 1000,2000,3000,5000,6000,7000 series.
Material:1015, 1060, 2011, 2014, 2017, 2024, 3003, 5005, 5052, 5154, 5056, 6106, 6201, 6011, 6351, 6060, 6063, 6061, 6005, 6082, 6463, 6262, 7003, 7075, 7050, 7005, etc
Type: Extruded, Welded, Extruded Seamless, Cold Drawn.
Shape: Round, Square, Rectangle.Manufacturing Technique: Hot Rolled, Cold Drawn, Cold Rolled, Forged.
Standard: AISI, ASTM, JIS, GB, DIN, etc. Related Standard: ASTM B210 / B210M, ASTM B241 / B241M, ASTM B221/ B221M, ASTM B 211 ASME SB 211 / ASTM B 619 ASME SB 619.etc
Surface: Mill, polished, bright, hair line, brush
Color:Silver, White,Bronze,Gold,Black,Champagne, Or customized
Film Thickness:Anodized:12-25 μm,Powder coating:40-80 μmAluminium Alloy Seamless Pipes
Aluminum 2014 | 2024 | 6061 | 6082 | 7075 Seamless pipes, Aluminum Alloy Seamless PipeAluminum Welded Pipes
Aluminium & Aluminium Alloy 2014, 2024, 6061, 6082, 7075 Welded Pipes Supplier, Aluminum ERW PipeAluminum Round Pipes & Tubes
Aluminium 2014 | 2024 | 6061 | 6082 | 7075 Round Pipes, Aluminum Alloy Round Tubes, Aluminum and Aluminum-Alloy Round PipeAluminum Square Pipes & Tubes
Aluminium 2014 | 2024 | 6061 | 6082 | 7075 Square Pipes, Aluminum Alloy Square Tubes, Aluminum and Aluminum-Alloy Square PipeAluminum Rectangular Pipes & Tubes
Aluminium 2014 | 2024 | 6061 | 6082 | 7075 Rectangular Pipes, Aluminum Alloy Rectangular Hollow Tubes, Aluminum Rectangle PipeAluminum Hexagonal Pipes & Tubes
Aluminium Alloy 2014 | 2024 | 6061 | 6082 | 7075 Hexagonal Pipe, Aluminium Hexagonal Tubes, Aluminum Hex Pipes -
Specification:
-
Aluminium Pipe Weight Calculation Formula
Weight = l / 1000 * w / 1000 * t * η
- l = length in mm
- w = width in mm
- t = thickness in mm
- η = Specific material density ( e.g.: steel = 7.85 kg / dm³)
Aluminium Pipe Size Chart
Manufacturer and supplier of Aluminium Hollow Pipe, Aluminium Gi Pipe in China, view 1/2 Aluminium Pipe weight chart & 3/4 Inch Aluminium Pipe dimensions
OM SIZE OUTSIDE
DIA (D)WALL THICKNESS IN MM (T)
METRIC SIZE SCH 10S SCH 10 SCH
40 SSTD Weight SCH 40 SCH 80s SCH 80 1/4 " 13.72 1.65 2.24 2.24 2.24 3.02 3.02 - 3/8" 17.15 1.65 2.31 2.31 2.31 3.2 3.2 1/2" 21.34 2.11 - 2.77 2.77 2.77 3.73 3.73 15 3/4" 26.67 2.11 2.87 2.87 2.87 3.91 3.91 20 1" 33.4 2.77 - 3.38 3.38 3.38 4.55 4.55 25 1 1/4" 42.16 2.77 3.56 3.56 3.56 4.85 4.85 32 1 1/2" 48.26 2.77 3.68 3.68 3.68 5.08 5.08 40 2" 60.32 2.77 - 3.91 3.91 3.91 5.54 5.54 50 2 1/2" 73.02 3.05 - 5.16 5.16 5.16 7.01 7.01 65 3" 88.9 3.05 - 5.49 5.49 5.49 7.62 7.62 80 3 1/2" 101.6 3.05 - 5.74 5.74 5.74 8.08 8.08 90 4" 114.3 3.05 - 6.02 6.02 6.02 8.56 8.56 100 5" 141.3 3.4 - 6.55 6.55 6.55 9.52 9.52 125 6" 168.27 3.4 - 7.11 7.11 7.11 10.97 10.97 150 8" 219.07 3.76 - 8.18 8.18 8.18 12.7 12.7 200 10" 273.05 4.19 - 9.27 9.27 9.27 12.7 15.08 250 12" 323.85 4.57 - 9.52 9.52 10.31 12.7 17.47 300 14" 355.6 4.77 6.35 - 9.52 11.12 - 19.05 350 16" 404.6 4.77 6.35 - 9.52 12.7 - 21.44 400 18" 457.2 4.77 6.35 - 9.52 14.27 - 23.82 450 Physical Property of 1050 1060 1070 aluminum tube pipe
Physical Property of 1050 1060 1070 aluminum tube pipe Alloy Temper Wall thickness
/mmRoom temperature Test Result Tension Strength/MPa Yield Strength/MPa Elongation/% A50mm A Not less than 1050 O、H111 All 60 ~ 100 20 25 23 H112 All 60 20 25 23 F All － － － － 1060 O All 60 ~ 95 15 25 22 H112 All 60 － 25 22 1070 O All 60 ~ 95 － 25 22 H112 All 60 20 25 22
-
2014 2017 2024 2A12 Aluminum Tube Pipe
Physical Property of 2014 2017 2024 2A12 Aluminum Tube Pipe Alloy Temper Wall thickness
/mmRoom temperature Test Result Tension Strength/MPa Yield Strength/MPa Elongation/% A50mm A Not less than 2014 O all ≤205 ≤125 12 10 T4、T4510、T4511 all 345 240 12 10 all 345 240 12 10 T42 all 345 200 12 10 T62 ≤18 415 365 7 6 >18 415 365 - 6 T6、T6510、T6511 ≤12.50 415 365 7 6 12.50~18.00 440 400 - 6 >18.00 470 400 - 6 2017 O all ≤245 ≤125 16 16 T4 all 345 215 12 12 T1 all 335 195 12 - 2024 O T3、T3510、T3511 ≤6.30 395 290 10 - >6.30~18.00 415 305 10 9 >18.00~35.00 450 315 - 9 >35.00 470 330 - 7 2024 T4 ≤18.00 395 260 12 10 >18.00 395 260 - 9 T42 ≤18.00 395 260 12 10 >18.00~35.00 395 260 - 9 >35.00 395 260 - 7 T81、T8510、
T8511>1.20~6.30 440 260 4 - >6.30~35.00 455 260 5 4 >35.00 455 260 - 4 2A12 O all ≤245 - - 10 T42 all 390 255 - 10 T4 all 390 255 - 10 Chemical Composition of 2014 2017 2024 2A12 Aluminum Tube Pipe Alloy Si Fe Cu Mn Mg Cr Ni Zn Ga V Ti Other Min.Al 2014 0.50-1.2 0.7 3.9-5.0 0.40-1.2 0.20-0.8 0.10 - 0.25 - - 0.15 0.15 Remainder 2017 0.20-0.8 0.7 3.5-4.5 0.40-1.0 0.40-1.0 0.10 - 0.25 - - - 0.15 Remainder 2024 0.50 0.50 3.8-4.9 0.30-0.9 1.2-1.8 0.10 - 0.25 - - 0.15 0.15 Remainder 2A12 0.5-1.2 0.70 3.9-5.0 0.4-1.2 0.2-0.8 0.10 - 0.25 - - 0.15 0.15 Remainder Physical Property of 2219 2A11 2A14 2A50 Aluminum Tube Pipe Alloy Temper Wall thickness
/mmRoom temperature Test Result Tension Strength/MPa Yield Strength/MPa Elongation/% A50mm A Not less than 2219 O all ≤220 ≤125 12 10 T31、T3510、T3511 ≤12.50 290 180 14 12 >12.50~80.00 310 185 - 12 T62 ≤25.00 370 250 6 5 >25.00 370 250 - 5 T81、T8510、T8511 ≤80.00 440 290 6 5 2A11 O all ≤245 - - 10 T1 all 350 195 - 10 2A14 T6 all 430 350 6 - 2A50 T6 all 380 250 - 10
3003 3A21 Aluminum Tube Pipe:Chemical Composition of 3003 3A21 Aluminum Tube Pipe Alloy Si Fe Cu Mn Mg Cr Ni Zn Ca V Ti Other Min.A1 3003 0.6 0.7 0.05-0.2 1.0-1.5 - - - 0.1 - - - 0.15 Remainder 3A21 0.6 0.7 0.20 1.0-1.6 0.05 - - 0.15 - - 0.10-0.20 0.15 Remainder Physical Property of 3003 3A21 Aluminum Tube Pipe Alloy Temper Wall thickness
/mmRoom temperature Test Result Tension Strength/MPa Yield Strength/MPa Elongation/% A50mm A Not less than 3003 O All 95 ~ 130 35 25 22 H112 ≤1.60 95 35 － － >1.60 95 35 25 22 F All － － － － 3A21 H112 All ≤165 － － － 5052 5083 5086 5154 5454 5456 aluminum tube pipe
Chemical Composition Alloy Si Fe Cu Mn Mg Cr Ni Zn Ga V Ti Other Min.Al 5052 0.25 0.40 0.10 0.10 2.2-2.8 0.15-0.35 - 0.10 - - - 0.15 Remainder 5083 0.40 0.40 0.10 0.40-0.10 4.0-4.9 0.05-0.25 - 0.25 - - 0.15 0.15 Remainder 5086 0.40 0.50 0.10 0.20-0.7 3.5-4.5 0.05-0.25 - 0.25 - - 0.15 0.15 Remainder 5154 0.50 0.50 0.10 0.50 3.1-3.9 0.25 - 0.20 - - 0.20 0.15 Remainder 5454 0.25 0.40 0.10 0.50-1.0 2.4-3.0 0.05-0.20 - 0.25 - - 0.20 0.15 Remainder 5456 0.25 0.40 0.10 0.50-1.0 4.7-5.5 0.05-0.20 - 0.25 - - 0.20 0.15 Remainder Physical Property Alloy Temper Wall thickness
/mmRoom temperature Test Result Tension Strength/MPa Yield Strength/MPa Elongation/% A50mm A Not less than 5052
O All 170 ~240 70 15 17 H112 All 170 70 13 15 F All - - - - 5083 O All 270~350 110 14 12 H111 All 275 165 12 10 H112 All 270 110 12 10 F All - - - - 5154 O All 205~285 75 - - H112 All 205 75 - - 5454 O All 215~285 85 14 12 H111 All 230 130 12 10 H112 All 215 85 12 10 5456 O All 285~365 130 14 12 H111 All 290 180 12 10 H112 All 285 130 12 10 5086 O All 240~315 95 14 12 H111 All 250 145 12 10 H112 All 240 95 12 10 F All - - - - 6005 6105 6041 6042 aluminum tube pipe
Chemical Composition Alloy Si Fe Cu Mn Mg Cr Ni Zn Ga V Ti Other Min.Al 6005 0.6-0.9 0.35 0.10 0.10 0.40-0.60 0.10 - 0.10 - - 0.10 0.15 Remainder 6105 0.6-1.0 0.35 0.10 0.10 0.45-0.8 0.1 - 0.1 - - 0.1 0.15 Remainder 6041 0.5-0.9 0.15-0.70 0.15-0.60 0.05-0.20 0.8-1.2 0.05-0.15 - 0.25 - - 0.15 0.15 Remainder 6042 0.5-1.2 0.70 0.2-0.6 0.40 0.7-1.2 0.04-0.35 - 0.25 - - 0.15 0.15 Remainder Physical Property Alloy Temper Wall thickness
/mmRoom temperature Test Result Tension Strength/MPa Yield Strength/MPa Elongation/% A50mm A Not less than 6005
T1 ≤12.50 170 105 16 14 T5 ≤3.20 260 240 8 - 3.20~25.00 260 240 10 9 6105 T1 ≤12.50 170 105 16 14 T5 ≤12.50 260 240 8 7 6041 T5、T6511 10.00~50.00 310 275 10 9 6042 T5、T6511 10.00~12.50 260 240 10 - 12.50~50.00 290 240 - 9
6061 6351 6082 Aluminum Tube Pipe
Chemical Composition of 6061 6351 6082 Aluminum Tube Pipe Alloy Si Fe Cu Mn Mg Cr Ni Zn Ga V Ti Other Min.Al 6061 0.40-0.80 0.7 0.15-0.40 0.15 0.8-1.2 0.04-0.35 - 0.25 - - 0.1 0.15 Remainder 6351 0.7-1.3 0.50 0.10 0.4-0.8 0.4-0.8 - - 0.20 - - 0.20 0.15 Remainder 6082 0.7-1.1 0.5 0.1 0.1-0.45 0.6-1.0 0.25 - 0.20 - - 0.15 0.15 Remainder 6162 6262 6064 6063 6066 6A02 aluminum tube pipe
Chemical Composition Alloy Si Fe Cu Mn Mg Cr Ni Zn Ga V Ti Other Min.Al 6162 0.4-0.8 0.5 0.2 0.1 0.7-1.1 - - 0.25 - - 0.1 0.15 Remainder 6262 0.4-0.8 0.7 0.15-0.40 0.15 0.8-1.2 0.04-1.4 - 0.25 - - 0.15 0.15 Remainder 6064 0.4-0.8 0.70 0.15-0.40 0.15 0.80-1.2 0.25 - 0.25 - - 0.15 0.15 Remainder 6063 0.2-0.6 0.35 0.10 0.10 0.45-0.9 0.10 - 0.25 - - 0.10 0.15 Remainder 6066 0.9-1.8 0.50 0.7-1.2 0.6-1.1 0.8-1.4 0.4 - 0.25 - - 0.2 0.15 Remainder 6A02 0.5-1.2 0.5 0.2-0.6 0.15 0.45-0.9 - - 0.20 - - 0.15 0.15 Remainder Physical Property Alloy Temper Wall thickness
/mmRoom temperature Test Result Tension Strength/MPa Yield Strength/MPa Elongation/% A50mm A Not less than 6162 T5、T5510、T5511 ≤25.00 255 235 7 6 T6、T6510、T6511 ≤6.30 260 240 8 － >6.3-12.50 260 240 10 9 6262 T6、T6511 all 260 240 10 9 6063 O all ≤130 - 18 16 T1 ≤12.50 115 60 12 10 >12.50~25.00 110 55 - 10 T42 ≤12.50 130 70 14 12 >12.50~25.00 125 60 - 12 T4 ≤12.50 130 70 14 12 >12.50~25.00 125 60 - 12 T5 ≤25.00 175 130 6 8 T52 ≤25.00 150-205 110-170 8 7 T6 all 205 170 10 9 T66 ≤25.00 245 200 8 10 F all - - - - 6064 T6、T6511 10.0-50.0 260 240 10 9 6066 O all ≤200 ≤125 16 14 T4、T4510、T4511 all 275 170 14 12 T42 all 275 165 14 12 T62 all 345 290 8 7 T6、T6510、T6511 all 345 310 8 7 6A02 O all ≤145 - - 17 T4 all 205 - - 14 T62 all 295 - - 8 T6 all 295 - - 8 7050 7075 7178 aluminum tube pipe
Chemical Composition of 7050 7075 7178 Aluminum Tube Pipe
Alloy
Si
Fe
Cu
Mn
Mg
Cr
Ni
Zn
Ga
Zr
Ti
Other
Min.Al
7050
0.12
0.15
2.0-2.6
0.10
1.9-2.6
0.01
-
5.7-6.7
-
0.08-0.15
0.06
0.15
Remainder
7075
0.40
0.50
1.2-2.0
0.30
2.1-2.9
0.18-0.28
-
5.1-6.1
-
-
0.20
0.15
Remainder
7178
0.40
0.50
1.6-2.4
0.3
2.4-3.1
0.18-0.28
-
6.3-7.3
-
-
0.20
0.15
Remainder
Physical Property of 7050 7075 7178 Aluminum Tube Pipe Alloy Temper Wall thickness
/mmRoom temperature Test Result Tension Strength/MPa Yield Strength/MPa Elongation/% A50mm A Not less than 7050 T76510 all 545 475 7 - T73511 all 485 415 8 7 T74511 all 505 435 7 - 7075 O、H111 ≤10.00 ≤275 ≤165 10 10 T62 ≤6.30 540 485 7 - >6.30-12.50 560 505 7 6 >12.50-70.00 560 495 7 6 T6、T6510、T6511 ≤6.30 540 485 7 - >6.30-12.50 560 505 7 - >12.50-70.00 560 495 - 6 T73、T73510、T73511 1.60-6.30 470 400 5 7 >6.30-35.00 485 420 6 8 >35.00-70.00 475 405 - 8 7178 O all ≤275 ≤165 10 9 T6、T6510、T6511 ≤1.60 565 525 - - >1.6-6.30 580 525 5 - >6.30-35.00 600 540 5 4 >35.00-60.00 580 515 - 4 >60.00-80.00 565 490 - 4 T62 ≤1.60 545 505 - - >1.6-6.30 565 510 5 - >6.30-35.00 595 530 5 4 >35.00-60.00 580 515 - 4 >60.00-80.00 565 490 - 4 Comparison of Alloy Designations for Aluminum Products
Alloy Series Chinese Standard American Standard European Standard 5xxx Series 5052 5052 EN AW-5052 5083 5083 EN AW-5083 5754 - EN AW 5754 6xxx Series 6005 6005 - 6060 6060 EN AW-6060 6061 6061 EN AW-6061 6063 6063 EN AW-6063 6082 6082 EN AW-6082 6463 6463 -
COOPERATIVE PARTNER
FAQ
FAQ
Q1:Can you send samples?
A:Of course, we can provide customers with free samples and express shipping service to all over of the world.
FAQ
Q2:What product information do I need to provide?
A:Please kindly provide the grade, width, thickness, surface treatment requirement should you have and quantities you need to purchase.
FAQ
Q3:It's my first time to import steel products, can you help me with it?
A:Sure,we have agent to arrange the shipment, we will do it together with you.
FAQ
Q4:What about product prices information?
A:Prices various according to periodic price changes of raw materials.
FAQ
Q5:What ports of shipment are there?
A:Under normal circumstances, we ship from Shanghai, Tianjin, Qingdao, Ningbo ports, you can specify other ports according to your needs.
FAQ
Q6:What is your terms of payment ?
A:Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shipment or based on BL copy or LC at sight.
FAQ
Q7.Do you have large amount of steel products in stock?
A: Yes , we have a large-scale indoor warehouse with perennial spot stocks totally above 200000 tons.
FAQ
Q8: Are you trading company or manufacturer ?
A: We are professional manufacturer for many years. we can provide a wide range of steel products.
FAQ
Q9:How long does your delivery time take?
A:In general, our delivery time is within 7-15 days, and may be longer if the quantity is extremely large or special circumstances occur.
FAQ
Q10: How many countries you already exported to?
A: We have exported to the United States, Canada, Brazil, Chile, Colombia, Russia, Ukraine, Thailand, India, Ghana, Somalia and other African countries.
